Chlorine Gas Leak Detector AQ-300

The chlorine gas leak detector is a highly accurate measuring device for measuring the chlorine concentration in our ambient air.Furthermore, sensor heads for other gases are also available for the chlorine measuring device, which are automatically recognized when they are plugged into the device.By using leading GSS Technology sensors, the Aeroqual gas leak detector has a high level of measurement accuracy and a very long service life for the sensor heads.

Highlights:

High accuracy and functionality

Easy to operate and maintain

Fast response time

Interchangeable sensor heads

LCD display

Battery operation

Alarm function

Sensor calibration function

Max. / Min. /Average function

Analog output

Specifications:

Alarm function includes "High", "Low", and Mute settings

Alarm output is a transistor output with a maximum of 150 mA, supporting Low Alarm, High Alarm, and Control

Analog output: 0 to 5 V

Location ID enables storage of the measuring location

Analog output: 0 ... 5 V

Power supply: 12 V DC

Rechargeable battery: Lithium-Polymer 12 V DC / 2700 mAh

Charger: 12.6 V 2 A

Charging voltage: 12.6 V

Charging time: 2 to 3 hours

Lifecycle: over 500 charges

Housing: PC & ABS / IP20 & NEMA 1

Dimensions (including sensor): 195 x 122 x 54 mm / 7.7 x 4.8 x 2.1"

Weight: less than 460 g / 16.2 oz (with batteries)

Approvals: EN 50082-1: 1997, EN 50081-1: 1992, CE

Refer catalogue for more information
