Rielta Zvon-1 version 1 - Glass Break Detection Sensor

Glass break detector Zvon-1 version 1.

Features:

Zvon-1 version 1 detects destruction of the following types of glass: regular, quenched,

patterned, armored, multilayer and protected with polymer tape (laminated), glass hollow blocks, as well as standard double and triple-chamber windows

Adjustment of sensitivity

Alarm output: energized Form A (NC) relay

Contents of the kit:

Glass break detector Zvon-1 version 1 - 1 pc.

Operational documentation

Code: sby00000048

Maximum detection range on the acoustic channel: 10 metres

Minimum area of secured glass: 0,1 m2

Voltage: from 9 to 17 V

Temperature range: from -20 °C to +45 °C

Protection class: IP30

Dimensions: 80х47х29 mm

Case opening control: Yes

Detection zone: Superficial

Current consumption in standby mode: 23 mА

Refer Catalogue For More Information
