Pneumatic Wheelchair Accessible Home Lifts - PVE52

Large enough to fit most full size wheelchairs as well as an attendant inside, the PVE52 home lift was built with comfort in mind. Able to transport up to 3 adult passengers, this residential lift is easy to install with minimal maintenance required. Combining a self-supporting design with pneumatic technology.

Combining a larger footprint and a more spacious interior, the PVE52 home lift is the perfect elevator for those seeking comfort and accessibility. Easy to install with minimal construction requirements, the largest Vacuum Elevator model has an exterior diameter of 1321 mm and is globally certified to transport up to 3 passengers or 238 kg. Fitting most full size wheelchairs as well as an additional passenger, this residential lift was designed for those seeking handicap accessibility or a more comfortable experience as you smoothly travel between levels.

Operating by vacuum suction and gravity, the PVE52 uses pneumatic technology to generate lift without utilizing any harmful oils, gases or lubricants. This air-driven elevator rests on the existing ground floor while not requiring a pre-construction shaft, pit or machine room for operation. Offering more flexibility of installation, this eco-friendly lift is plugged into your wall via a 220 volt, single phase power supply with minimal maintenance required.

Ideal for both retro-fit and new construction projects, this wheelchair home lift has an attractive design that provides a 360° degree view while traveling. Manufactured using an aluminum frame and polycarbonate panels, this panoramic elevator offers infinite design possibilities. Never has accessibility been as affordable, attractive or simple as the PVE52 home lift!

1321 mm Exterior Diameter

238 kg Lift Capacity

No pit, hoist way, or machine room required

Self supporting structure

50 ft (15m) Total Rise Max

30 ft/M travelling speed

Two to Five Stops

External cylinder diameter: 52 11/16 inches (1321 mm)

Internal cabin diameter: 43 1/2 inches (1118mm)

Internal cabin height: 6’7” (79 inches/ 2007mm)

Entrance way opening: 32 inches (813mm)

Through Floor or Balcony Mount Landings

Power Supply: 35 AMP 220VAC

In-line or 180° Door Openings

Aluminum and polycarbonate cylinder structure

Automatic interior LED lighting and fan

Mechanical emergency safety brake system

One year limited manufacturer warranty

ASME A17.7 Certified
