Narang Medical HF1042A : ICU Bed Electric 5 Function With Weighing Scale

NET brand HF1042A - ICU Bed Electric 5 Function With Weighing Scale is a high-quality product and trusted all across the globe. HF1042A - ICU Bed Electric 5 Function With Weighing Scale is being manufactured and supplied by the company reputed because of excellent product quality, friendly service and professional approach. Scroll down to see specifications and reviews.

Electric Parameters:

Power supply : 220V/110V, 50HZ / 60HZ

Maximum input : 1.6A, 450VA

Protection against water and dust : IPX4

Equipment security classification : Class II

Level of protection against injury from electrical current : Applied part type BF

Electric motor operation mode (load factor) : 10%, max. 2 min/18 min

Standard Features:

ICU Bed (5 function) with electrically operated back rest tilting 0-70°, knee rest tilting 0-30°, trendelenburg tilting 0-12°,Reverse trendelenburg tilting 0-12

Outer dimensions L2240*W1060mm (±10mm) (Side rails up), Mattress platform L1965*W920mm (±10mm), Bed Height H520-920mm (±10mm), Bed extension 200mm (±10mm). All function controlled with TiMotion motor.

Split Guard Rails: Guard rail PP- 4pcs provides protection to patient against fall.

Angle Gauge on Side rails display the angle of back rest and Trendelenburg / Reverse Trendelenburg.

Removable mattress platform: Plastic board mattress platform can be easily removed for sterilization.

With X-ray permeable PF backrest, Central nurse control system, 150mm noiseless castor with central locking.

Embedded controls on both sides of guard rails

H/F boards locks :The board locks prevent accidental removal of the bed boards when steering or handing the bed

X-ray cassette holder: Special sliding construction allows the cassette to be comfortably inserted beneath the mattress platform from the side of the bed. With Weighing scale

Manual/Electric CPR: The Electric CPR is easy and convenient to operate with one key control. Manual CPR is equipped with damping device, which can be used single handedly and allows the back rest fall slowly to ensure the safety of the patient, in case of power failure.
