Matronix A Scan

An advanced diagnostic device intended to deliver precision and reliability in ophthalmic measurements is the Matronix A-Scan Biometry. This compact system integrates essential functions and technical accuracy, making it a dependable tool for eye care professionals in clinical environments.

The diagnostic efficiency is significantly enhanced by the Matronix A-Scan, which ensures accurate and repeatable measurements of critical ocular parameters such as axial length, anterior chamber depth, and vitreous length. With ±0.1 mm accuracy and 0.01 mm resolution, it supports detailed assessments for treatment planning. The device offers both contact and immersion modes, along with automatic and manual options, providing flexibility in operation.

Its support for multiple examination types—including Normal, Aphakic, Pseudophakic, and Dense Cataract modes—makes it suitable for a wide range of patient conditions.

Features:

Primary Purpose : Biometry & IOL calculation

Scan Type : A-Scan only

Probe Frequency : 10 MHz

Measurement Accuracy : ±0.1 mm

Resolution : 0.01 mm

Measurement Parameters : ACD, Lens, Vitreous, AXL

Measurement Range : 15–35 mm

Examination Modes : Normal, Aphakic, Pseudophakic, Dense Cataract

Measurement Technique : Immersion & Contact (Auto/Manual)

Imaging Output : —

Gray Scale Imaging : —

Monitor Size : 4.7 inch

Battery Operation : optional battery support

Portability Focus : Compact diagnostic unit

Main Unit Weight : 2.5 kg

Clinical Use Case : IOL power calculation

Dimension : 200*168*165(mm,L*W*H)

Gain Adjustable : 0-120 dB

Measurements : ACD,Lens,Vitreous,and AXL

Iol Formulas : SRK-II,SRK-T,BINKHORST,HOLLADAY,HOFFER-Q,HAIGIS Power requirement AC 100-240V 50-60Hz
