Prime Cold Room Panels

₹1,200/Sq.mtOnwards

info

This will be an indicative price and not the exact price of the product

Description

Cold Room Panel, is a factory made insulated wall panel, having metal facing combined with polyurethane foam core. The panel has a width has a width of 1170mm with length upto 12.0 meters. The side joint is formed with tongue and groove.

Specification

Panel Specification :

Width : 1170mm

Maximum length up to : 12 metres

Thickness of panel 30 to 200mm

Core :

Self bonding polyurethane foam

Facings :

Polyester coated aluminium, aluzinc, stainless sted or FRP

Density – 40kg/m K-value : 0.027w/m-k

“U” value (W/m - C) :

Thickness : ""U"" Value

50mm : 0.54

100mm : 0.27

150mm : 0.20

200mm : 0.14"
