Robust & reliable (Scottish design)
Pressure rating up to PN 16 (50 to 2000 mm NB)
Suitable for Raw, Clear, Waste & Sea water
Tailor made for special applications and corrosive fluids
Minimal maintenance
General conformity to IS 14846 / BS EN 1171 / BS 5163
Flanges faced and drilled to IS 1538 table 4 & 6 / IS 9523 / BS EN 1092-2
Length Over Flanges : PD of IS 14846/ISO 5752 Basic Series 3
Operation – Manual thru hand wheel or gearbox / Electric / Pneumatic / Hydraulic / Head stock
Optional Accessories:
Back Seat Bush – Bronze – for 200 NB and above (for re-packing under pressure)
Shoe & Channel – Bronze / SS 304 – for 400 NB and above (not recommended for sewage duty)
Ball thrust bearings (anti friction) – 400 NB and above
Gear Box – ‘TMI’ make enclosed spur / worm / bevel with or without Mechanical Position indicator – 200 NB and above
Drain Plug – 400 NB and above
By-Pass arrangement - 400 NB and above
Head stock operation
Chain wheel operation
