SI Surgical ETO Sterilizer - SIS 4000WD

Washer Disinfector

Size: 600 X 600 X 800 MM

Capacity: 275 Liters Door: Single Door

Description of Goods

Application:

The Washer Disinfector is primarily used for washing & disinfecting of: Surgical Instruments, Feeding bottles. Dentist trays. Kidney basins. Dressing bowls, Glass articles. Etc. Optionally the Washer Disinfector can also be accommodated with a drying function.

Chamber Size & Fabrication:

600 (w) x 600 (h) x 800 (d) mm.

The chamber is fabricated from S. S. 304 Stainless Steel with full argon welding.

The chamber is provided with an adequately sized sump & drain at the bottom.

The outer paneling fabricated from stainless steel is easily removable for maintenance & servicing 1 No.

Door Sliding:

Double doors with quick locking arrangement & with silicone gasket seal.

Cleaning System:

The Chamber is provided with 4 rotating spray arms- 1 at top, 2 in middle & 1 at bottom. The middle spray arm is provided for docking. The rotating arm is revolved due to pressure of cleaning medium resulting in a uniform spray over the load.

Circulating Pump:

A circulating pump with large runoff is provided for effective cleanout over the objects with round movements of water ejection through rotating arms. The circulating pump is driven by a TEFC, 3phase electric motor

Detergent Dozing:

A container with lid is provided for automatic loading of detergent.

Design ensures easy adding of fresh detergent before every cycle

Piping:

All stainless steel piping with full argon welding.

All piping is of S. S. 304 Stainless Steel.

All valves have S. S. 304 contact parts with Teflon seat.

All welding is argon welding.

Control System:

Microprocessor controller with easy-to-use operator interface.

Preprogrammed for simple use. PROG 1: Instruments PROG 2: Kidney bowls/trays/basins. PROG 3: Bottles PROG 4: Tubing’s

All time & temperatures are user settable.

Possibility to repeat or skip a particular phase.

Password protection for un-authorized access.

2 x 16-character LCD display for on-line messaging. HMI & PLC: KINCO
