Gnatus S300 H Dental Unit

The S300 H Dental Unit with features designed for the dentist’s maximum performance. Its upholstery is wider and more comfortable, with availability in PVC, viscoelastic or leather. The delivery unit is pneumatic, with conventional rods and locking retractable rods. The water unit also offers as an option the suctor terminal with a vacuum pump and the dental light has the economy of LED light.

Power supply : 127/220 V (Internally selectable)

Frequency : 50/60 Hz

Type of Protection against Electric Shock : Class I Equipment

Degree of Protection against Electric Shock : Type B Applied Part

Mode of operation : Continuous, intermittent load - 1 min. work and 4 min. rest

Protection against harmful water penetration : IPX 0 - The whole examination chair, except the foot control pedal, IPX 1 - Foot control

Input power : 200 VA

Protection Fuses : F1 and F2 (127 or 220V~ = 5A) delayed action

Maximum recommended load on the chair : up to 200 kg

Maximum capacity of load applied in the trays of equipments : 2 Kg

Net Weight : 120 Kg

Color : Black, White

Features :

Proximity Sensor - Activates the water in the ceramic spittoon automatically

Led Dental Light - With multifaceted mirror and bilateral handles

Multifunctional Foot Control - More agility and biosecurity for your dental unit
