FAAC FG1 – FG2 - Metallic Mass Detectors

FG1 – FG2 Metallic mass detectors

System type: Pulse generators for special applications

Features:

Inductive vehicle detection system

Suitable for controlling barriers, gates and access control systems

Relay outputs with clean contacts

Identification of presence or position

Fastening on DIN rail

Family models:

FG1: Metallic mass detectors : 785529

FG2: Metallic mass detectors : 785527

Dimensions and Technical

Number of connectable turns: 1 : 2

Power supply voltage: 24V – 24V~

Contact ratings: 250 mA / 24V

Sensitivity levels independent from loop inductance: 4

Installation type: On DIN guide

Operating ambient temperature: -20°C ÷ +55°C
