Type: Discrete
Finish: Textures
Core: Glassfibre
Thickness (mm): 40
Size (mm): 600x600, 1200
Density (Kg/m3): 120~140
Weight (Kg/m2): 4.8~5.6
Fire (Class): 1 & P
NRC: 0.9
Thermal (W/mk): 0.07
Climate (0C, RH): 40, 95
Light (%): Print dependant
Green (VOC, RC%): Low, 35
Warranty (Years): 5
Maintenance: Vacuum, Dry-Wipe
Install Accessories - Ceiling:
A-Chain hardware or Suspension Kit consists of Corkscrew, Levelling hook and Hangar wire by Anutone.
2 kits @ 500, 1000mm centres recommended for baffle height 600, 1200mm respectively.
B-Chain hardware consists of Anchor bolt, Soffit cleat and S-hook by others (not by Anutone).
