Esco Air Eliminator / Air Vent

Series : SSAE

Description : Bottom Inlet Top Outlet

Flow :

Sizes : 1/2"-1"

Body Materials : AISI 304

End Conn : Screwed/ Flanged

PMA : 600 PSI (42 Bar)

Principle:SSAE Series and AEBFH air eliminators operate on difference in density between gas and liquid while TAV300 operates on difference in temperature between steam and air. SSAE and AEBFH are used for liquid and TAV300 is used for steam.

Body Material:

Cast Iron (ASTM A48 Cl. 30)

Ductile Iron (DIN 1693 GGG40)

Cast Steel (ASTM A216 Gr.WCB)

Stainless Steel(ASTM A351 Gr CF8, AISI 304)

Forged Steel (ASTM A105)

End Connection:

Screwed to BSP, BSPT, NPT

Flanged to ANSI, DIN, BS

Socket Weldable
