Securiton Aspirating Smoke Detector

With SecuriSmoke ASD aspirating, you can get an early warning against fires with the most precision and reliability possible. For any monitoring area, Securiton offers the world's leading technology that offers lightning-fast fire detection both scalable and cost-effective. The ASD 532 is a continuous air sampling smoke detector that collects air samples continuously from a monitored area and feeds them to a smoke sensor.

Highly sensitive smoke detector

Sensitivity can be set between- 0.002–10 %/m

robust smoke detection

Low noise level, compliant with ISO 11690-1

measurement resolution < 0.001 %/m

Single Tube with two tube device

UL & VdS Approved

Up to 5 alarm levels per detector (3 pre-signals and 1 or 2 alarms)

Technical specification:

Smoke sensor : Highly sensitive smoke detector with Led, Lvsc smoke chamber

Channels : 1

Monitoring area : 1280 m2

Refer catalogue for more information
