Secure K12 Crash Rated Automatic Bollards (M50) - Arjuna 1200 (SAB 1200)

The M50 Automatic Bollard is a high-security, retractable rising bollard that prevents unauthorized vehicle access while allowing free pedestrian movement. The units are designed in accordance with internationally accepted standards such as ASTM, DOS, PAS68, and IWA14. This bollard also offers an emergency fast operation option with a response time of 2 seconds.

K12 (M50)

Technical Specification :

Crash Rating : K12 (M50)

Blocking Height : 1000 mm / 1200 mm

Blocking Diameter : 275 mm / 355 mm

Installation Depth : Approx. 2000 mm

Drive Unit : Hydraulic

Power : 3-phase 400VAC 50Hz

Opening/Closing Time : 3–6 Sec

Safety : Line of Photocells, Loop Detectors, Microwave Radars (SMR 40)

Electrical Cabinet Unit : In separate cabinet

Operating Temperature : -30°C to +60°C (optional +70°C)

Optional Equipment : Control console, PLC, Inbuilt Hydraulic Power Unit and others
