Type: Grid
Finish: Textures
Core: Glassfibre
Thickness (mm): 30
40
Size* (mm) diameter:
600
1000
1200
Density (Kg/m3): 120~140
Weight (Kg/m2): 3.6~5.6
Fire (Class): 1 & P
NRC: upto 0.9
Thermal (W/mk): 0.07
Climate (0C, RH): 40, 95
Light (%): 85
Green (VOC, RC%): Low, 35
Warranty (Years): 3
Maintenance: Vacuum, Damp-Wipe
Install Accessories - Ceiling : A-Chain hardware or Suspension Kit consists of Corkscrew,
Levelling hook and Hangar wire by Anutone.
4 kits recommended per Cloud. Skelet T24
White
Ebony
Colour by Anutone for cluster pattern optional.
B-Chain hardware consists of Anchor bolt, Soffit cleat and
S-hook by others (not by Anutone).
Remarks: Use ‘bud’ touch-up technique for surface scratches, if any, during handover
