Kallerians Industrial Air Curtains

Industrial air curtains, Insect barrier air curtains are heavy duty air curtains. It is made for preventing insects and it blows air at the velocity of 20 – 22 m/sec. For normal usage industrial air curtains can fitted at 11 to 12 feet height. The same air curtain has to be placed at the level of 8 ft for preventing insects. This air curtains are operated with 3 phase power only.

Width : 380mm

Height : 380mm

Length : 3ft / 4ft / 5ft / Custom build available.

Weight : 37 – 85 Kg ( from 3ft – 6ft )

Power Consumption : AC 440 Volts – 3 Phase

Application: Pharmaceutical Industry, Food Processing Industry, Meat Processing Industry

1, 1.5 Horse power motors.

Epoxy Powder coated, Complete stainless steel 304 or 316 grade one piece construction.

Unbeatable air flow uniformity.

Available filters for improved air quality.

Exceptionally low noise levels.

Available in single phase, three phase and flame proof motors against custom build.

1 year guarantee.

Refer brochure for more information.
