Camera
Image Sensor: 1/4" Mega Pixels Cmos
Chipset: H62 + Fh8532E
Effective Pixels: 1280 (H) X 720 (V).
Lowest Illumination: 0.02 Lux @ (F1.2, Agc On), 0 Lux With Ir
Electronic Shutter: 1/ 50S ~ 1/ 60,000S.
Video System: Pal/ Ntsc
Video Frame Rate: 25/ 30 Fps @ 700 Tvl.
Video Output: 1 Channel, 700 Tvl.
Video Switch: 2 Bit Switch.
Smart Ir Control: Support
Day/ Night: Auto (Icr)/ Color/ B/W.
Wdr: D-Wdr
Osd Menu: Support, Coaxial Cable Control Via Dvr Directly (Utc)
Other Function: Awb, Agc, Blc.
Genral:
Power Supply: Dc 12V ± 10%.
Power Consumption: < 5W.
Working Environment: -30°C ~ + 60°C/ Less Than 95% Rh.
Ir Led: 5 Pcs. Ir Array Led.
Ir Distance: 20 - 30M Ir Distance.
Lens: 3.6Mm Fixed Lens.
Transmission Distance: Over 300M Via 75 - 3 Coaxial Cable
