Component : Material Specification
Body : CI / SGI / WCB / CF8 / CF8M
Disc : CI / SGI / WCB / CF8 / CF8M
Shaft : AISI- 410 / 304 / 316
Seat : Nitrile / EPDM / Neoprene / Silicon / Viton.
Bush Bearing : Self Lubricating Sintered Bronze
Design Standard : As per IS- 13095 / BS- 5155 / BS EN - 593, AWWA - C - 504
Pressure Rating : PN - 10.PN - 16
Class : 125 / 150
Temp. Range : -20° To + 180oC
Face to Face : ISO- 5752 / BS 5155 Wafer short / API 609
Dimension : Hand lever - DN - 40 to ON 150
Actuation By : Gear Operated DN - 200 to DN - 1200
End Connections : Wafer- Flangeless & Double Flanged
Suitable for Mountinq Flanges : IS / ANSI / BS / DIN Standards
Testing Std. : BS 6755 (1) / API 598 / AWWA - C - 504
