SI Surgical Defibrillator - 100A

Model: Adult DDP 100P, Child/Infant DDP 200P Type Pre connected, Single-use, non-polarized, dispos-able, self-adhesive electrodes with cable and Connector Surface Area 103cm (nominal, each pad) 50cm (nomi- terly nal, each pad) Pad Pacement Adult-Anterior Child - Anterior/Infant-Anterior & Posterior.

Internal Event Record Critical ECGSegments and rescue event parameters rerecorded and can be downloaded to a removable data card

Removable Storage (Optional) Up to 12 hours of ECG and event data storage (no audio option) or up to 2 hours of audio, ECG and event storage (audio option) on a removable data card. Actual length of storage is dependenton card capacity

Type Lithium/Manganese Dioxide Disposable, recycla-ble, non-rechargeable Lowbattery indicators Visible, Audible

User-initiated Unit and battery pack system test may also be initiated by the user Status indication Visualand audible indication of units sta.

Technical Specifications :

Defibrillator

Type : Semiautomatic external defibrillator

Waveform : Biphasic Truncated Exponential (Impedance compensated)

Energy Adult : 150 Joules paediatric: 50 Joules (Nomi- nal in 500 Load)

Charge Time : Less than 6 to 9 seconds

Voice Prompts : Extensive voice prompts guide user through operation of the unit and CPR

CPR Pacing Metronome

Controls Lighted On/Off button Lighted Shock button

Indicators

Check Pads

Do not touchPatient

Analyzing AED Status LED-Defibrillation / Monitoring Type

Cable Length (typical) : 48" (122cm)

Optional : Fully Automatic External Defibrillator

Event Documentation

Non rechargeable lithium/manganese dioxide disposable (removable) battery

Battery Pack

Power 15V, 2800tnAh/1400mAh

Capacity 300Shocks or Approx. 16 hours continuous operation

Standby life 5 to 7 years

Self Tests

Automatic Automatic daily, weekly, monthly and quar- terly circuitry tests

Battery insertion System integrity teston battery inser-tion

Pad presence Pads pre-connected tested daily

Size : 8 5x11.8x2.7inches

Weight : 4.4 lbs (20Kg)
