Type: Non-Grid
Finish: Woods
Core: Pinewood HDF (Beige, Pink(FR), Green(MR), Ebony)
Thickness (mm): 16
Size (mm): 128
192 x 2440
Density* (Kg/m³): 700
Weight (Kg/m²): L16 – 9, L32 – 10.5, L64 – 11
Acoustic Fleece**: 0.27mm, 63g/m²
Fire** (Class): 1 & P
NRC: L32-C18 – 0.65, L32-C40 – 0.75
Thermal (W/mK): na
Climate (°C, RH): 50, 70
Light (%): 75 (Maple Arce)
Green (VOC, RC%): E1, 25
Warranty (Years): 5
Maintenance: Dry-wipe, Vacuum
Install Accessories - Ceiling:
Strut SA25, WC25, MC45, CC25, CC18, SynthPF, Center & Edge Bracket by Anutone.
Anchor bolt, soffit cleat, fasteners by others.
Install Accessories - Panelling:
Strut CC10
CC25
CC50 with CC18, SynthPF, Stick S7, Center & Edge Bracket by Anutone.
Fasteners by others.
*for unperforated base board
**for FR grade
